K-TIGER EX-C
K-TIGER EXC
K-TIGER EXC
Contact Us For Detail Information
Contact Us For Detail Information
Diesel Euro 5
Passenger/Logistics
W112
| DIMENSION | ||||
| OVERALL DIMENSION | LENGTH | 5918 | ||
| WIDTH | 2020 | |||
| HEIGHT | LOW-DECK | 2360（2530） | ||
| HIGH-DECK | 2620（2800） | |||
| WHEEL BASE | 3665 | |||
| TREAD SINGLE | FRONT | 1700 | ||
| REAR | 1720 | |||
| TREAD DOUBLE | FRONT | 1689 | ||
| REAR | 1525 | |||
| FRONT OVERHANG | 1025 | |||
| REAR OVERHANG | 1228 | |||
| INTERIOR CARGO DIMENSION | LENGTH | 3265 | ||
| WIDTH | 1780 | |||
| HEIGHT | LOW-DECK | 1650 | ||
| HIGH-DECK | 1940 | |||
| NUMBER OF SEATS | 15 (13+1+1) | |||
| WEIGHT | CURB WEIGHT | 2800 | ||
| GVM | 4990 | |||
| MAX. SPEED (Km/h) | 130 | |||
| MAX. GRADABILITY | 20 | |||
| MIN. TURNING DIAMETER (m) | 13.5 | |||
| Power | Engine | Model | K-TIGER EX-C |
| Manufacturer | KHM | ||
| Horse-Power | 140 | ||
| Power-Rate (Kw/rpm) | 103 | ||
| Torque (N.m/rpm) | 350 | ||
| Emission Standard | Euro 5 | ||
| Displacement (cc) | 2360 | ||
| Transmission | 6 M T | ||
| Drive Type | RWD | ||
| Rear Axle | Load Capacity | Single Tyre | 2500 |
| Double Tyre | -- | ||
| Tyre | Single Tyre | 215/75R16LT | |
| Double Tyre | -- | ||
| Body Structure | All-bearing pressing and welding body | ||
| Front Suspension Type | Spring Independent Suspension | ||
| Rear Suspension Type | LEAF SPRING Non-independent | ||
| Feature | Availability |
|---|---|
| Standard painting (White) | • |
| Closed side window in passenger area (white glass) | • |
| Front electric left right side windows | • |
| Crystal and halogen headlamps | • |
| Rear doors | • |
| Steel wheels | • |
| 6 direction adjustable driver seat | • |
| Passenger seat with fabric cover | • |
| CAN-BUS diagnostics | • |
| Vehicle anti-theft | • |
| ABS/EBD | • |
| Three-point seat belt for driver seat with alarm | • |
| 3-point seat belt for passenger seat | • |
| Instantaneous fuel consumption display | • |
| Sustainable mileage display | • |
| High position brake lamp | • |
| MP3/Radio | • |
| Electric turn and signal integrated rearview mirror | • |
| Full frequency speaker | • |
| 12000kcal front and rear air conditioner | • |
| Folding remote control key | • |
| Delay headlamps | • |
| Automatically unlock | • |
| Automatically lock (≥15kmh) | • |
| Passenger sliding door | • |
| Multifunction steering wheel | • |
| Front fog lamp | • |
| LED daytime driving lights | • |
| Central lock | • |
| Feature | Availability |
|---|---|
| Metal paint (Black color) | ○ |
| Sliding side window (Grey color) | ○ |
| Aluminum alloy wheels | ○ |
| Single airbag (Driver only) | ○ |
| Double airbag (Driver and co-driver) | ○ |
| Electric greeting pedal | ○ |
| Manual folding TV | ○ |
| Electric folding TV | ○ |
| WiFi Integrated w/WiFi | ○ |
| Digital clock | ○ |
| MP5 Reversing Monitor | ○ |
| Parking radar | ○ |
| Curtain for all side windows (Same color with interior) | ○ |
| Double passenger seats near driver | ○ |
| DVR | ○ |
| Fire extinguisher | ○ |
| Tyre Pressure Monitoring System (TPMS) | ○ |
| Automatic Transmission | ○ |
| Front outer swing door | ○ |
| Inside roof luggage rack （left side only） | ○ |
