K-TIGER EX-M
K-TIGER EXM
K-TIGER EXM
Contact Us For Detail Information
Contact Us For Detail Information
Diesel Euro 5
Passenger/Logistic
W611
| Basic Specification | ||||
|---|---|---|---|---|
| Dimension (mm) | Overall Dimension | Length | 6940 | |
| Width | 1993 | |||
| Height | Low-Deck (A/C) | -- | ||
| High-Deck (A/C) | 2620（2800） | |||
| Wheel Base | 4325 | |||
| TREAD (Single) | Front | -- | ||
| Rear | -- | |||
| TREAD (Double) | Front | 1689 | ||
| Rear | 1525 | |||
| Front Overhang | 1025 | |||
| Rear Overhang | 1590 | |||
| Interior Cargo Dimension | Length | 4250 | ||
| Width | 1780 | |||
| Height | Low-Deck | -- | ||
| High-Deck | 1940 | |||
| Number Of Seats | 10-22/1-3 | |||
| Weight | Curb Weight | 3500/3100 | ||
| G V M | 5000 | |||
| Max. Speed (Km/h) | 120 | |||
| Max. GradAbility | 20 | |||
| Min. Turning Diameter (m) | 16 | |||
| Power System Specifications | |||
|---|---|---|---|
| Power | Engine | Model | K-TIGER EX-M |
| Manufacturer | KHM | ||
| Horse-Power | 140 | ||
| Power-Rate (Kw/rpm) | 103 | ||
| Torque (N.m/rpm) | 350 | ||
| Emission Standard | Euro 5 | ||
| Displacement (cc) | 2360 | ||
| Transmission | 6 M T | ||
| Drive Type | RWD | ||
| Body & Suspension System | |||
|---|---|---|---|
| Body Structure | LHD | ||
| Front Suspension Type | Spring Independent Suspension | ||
| Rear Suspension Type | Leaf Spring | ||
| Rear Axle | Load Capacity | Single Tyre | -- |
| Double Tyre | 3500 | ||
| Tyre | Single Tyre | -- | |
| Double Tyre | 195/75R16, 205/75R16 | ||
| Standard | |
|---|---|
| Standard painting (White) | YES |
| Closed side window in passenger area (white glass) | YES |
| Front electric left & right side windows | YES |
| Crystal and halogen headlamps | YES |
| Rear doors | YES |
| Steel wheels | YES |
| 6 direction adjustable driver seat | YES |
| Passenger seat with fabric cover | YES |
| CAN-BUS diagnostics | YES |
| Vehicle anti-theft | YES |
| ABS+EBD | YES |
| Three-point seat belt for driver seat with alarm | YES |
| 3-point seat belt for passenger seat | YES |
| Instantaneous fuel consumption display | YES |
| Sustainable mileage display | YES |
| High position brake lamp | YES |
| MP3+Radio | YES |
| Electric turn and signal integrated rearview mirror | YES |
| Full frequency speaker | YES |
| 10000kcal front heating & air conditioning | YES |
| Folding remote control key | YES |
| Delay headlamps | YES |
| Automatically unlock | YES |
| Automatically lock（≥15km/h） | YES |
| Passenger sliding door | YES |
| Multifunction steering wheel | YES |
| Front fog lamp | YES |
| Iron hub | YES |
| Central lock | YES |
| Optional | |
|---|---|
| Metal paint | Optional |
| Double sliding door in right side | Optional |
| Electric side sliding door | Optional |
| Front swinging door | Optional |
| Sliding side window | Optional |
| Aluminum alloy wheels | Optional |
| Electric greeting pedal | Optional |
| Manual / electric folding TV | Optional |
| Integrated WIFI | Optional |
| 12000kcal front heating & air conditioning | Optional |
| Curtain for all side windows | Optional |
| All leather seats -microfiber fabric | Optional |
| Gray glass | Optional |
| LED daytime driving lights | Optional |
| Rear window electric heating defrosting | Optional |
| Roof luggage rack | Optional |
| DVR | Optional |
| Fire extinguisher | Optional |
| Tyre Pressure Monitoring System(TPMS) | Optional |
▪ Layout Sample
